Description
Based on TCP/IP technology, the product supports the 48V standard PoE, making it more flexible for installation.
Main Features
• Android 10 OS
• 7-inch IPS LCD Capacitive Touch Screen
• 1024×600 screen resolution
• RAM: 2GB , ROM: 8GB
• CPU: Quad-core ARM Cortex™-A53 @ 1.5GHz
• Built-in Tuya ZigBee 3.0 & Bluetooth gateway
• Home automation, Elevator linkage, IP Camera integration
• Support 2.4GHz Wi-Fi, and Ethernet network
• Support Tuya app, SmartLife app, or 3rd-party apps
• Multi-unit synchronization (Villa & Apartment system in one)
• Communication mode: RJ45(TCP/IP), RS485, WiFi, ZigBee, BLE 5.0
• Video record for calls
• Powered by 48V PoE or DC 12V
• 1-Channel Doorbell
• 8-Channel wired Alarm input
• 86 Box Magnetic suction installation
Details
| Colour | Black |
|---|---|
| Material | Glass panel + ABS body + ABS shell |
| Installation | Surface Magnetic mount |
| Dimension (H.W.D) | 147×200×16 MM |
