Description
The product is suitable for Small Places such as homes, independent offices, shops, warehouses, industrial parks, and other scenarios.
Main Features
• Access mode: APP, Fingerprint, Card, PIN
• 10500 User Capacity (500 Fingerprint+9988 Card/PIN+2 panic+10 visitor), 500 APP users
• Touch keypad + Capacitive fingerprint sensor + OLED display
• Card type: 125KHz EM Card
• Can set time restrictions for users
• Temporary PIN (One-time or Period), 4-6 digit PIN
• Add / Delete users via the APP
• Wiegand 26~44 bits input & output
• Relay: 1 (NO, NC, COM)
• Interface: Relay output, Exit button, Alarm, Door contact, Wiegand input/output
• IP66 Waterproof
• DC 12~18V
• Physical: ABS Shell
• Color: Black
• Dimensions: 148 x 43.5 x 22 mm
Details
| Colour | Black |
|---|---|
| Material | ABS |
| Installation | Surface mount |
| Dimension (H.W.D) | 148 x 43.5 x 22 MM |
